Multi Drying Machine

Exposure and Drying Machine Automatic

Description: In order to save costs and reduce machine footprint, customers can choose our light finisher and drying machine. there is a spacer layer between the adhesive and the baking plate to prevent ozone dama
INQUIRY EMAIL

Performance: 1.Drawer type light finisher layer and drying layer, UVA and UVC mixed light source for light finisherlayer 2.built-in effective air exhaust device to effectively discharge ozone

3.each section temperature control, can be adjusted of independently, different types of plate can be managed separately

4.Drawers are insulated of reduce heat loss and minimize energy consumption.

5.Drawers are equipped with air intake grooves and built-in high-strength fan, to allow real aircirculation ,fast heat transfer and uniform temperature regulation,

Model	LFD Light Finisher Post Exposure and Drying Machine
Plate Size(Max)	1430x920	1520x1060	2030x1060	2030x1320	2540x1320
Power Supply	5.3KW 50-60 HZ	8.2KW 50-60 HZ	9.2KW 50-60 HZ	11.8KW 50-60 HZ	13KW 50-60 HZ
Power Supply	220V L+N+E.220VAC		L+N+E, 220VAC / 3L+N+PE,380VAC
Air Exhaust	1000M³/H	1500M³/H	1800M³/H	2000M³/H	2500M°/H
Dimensions (Lxwxh)	21601480900	23601720900	30201720900	30202000900	3560x2000x1000
Weight, Equipment	450KG	520KG	600KG	650KG	700KG
