Flexible Exposure Machine

SUV-LED Scan LED Flexo Plate Exposure Machine

Description:
INQUIRY EMAIL

1.vacuum platform, can use LED for analog flexo plate, breathable vacuum leather pad, good air conductivity make the plate and film closely fit, truly and accurately reproducing the film pattern

2. Imported LED chip matrix, water-cooling system, uniform luminance，cold light source for exposure, non-heating for glass, preventing film deformation, thus truly ensuring 1:1 presentation of
the pattern.

3. Driven by a servo system, each position receives equal energy illumination from the illuminated area.

4. Scanning exposure ensures uniform exposure of the entire pattern, strong ability to penetrate photosensitive adhesive, and eliminates the phenomenon of serrated edges of ultrafine lines.

5. LED light sources consume less energy, are concentrated in energy, have a long service life, and consume 8-10 times more energy than regular print lamps.

6. The LED light source is an instant on/off type light source, which does not require preheating to start, and can be exposed immediately, improving the efficiency of exposure plate making.

7. According to the characteristics of different photosensitive adhesives, different exposure scanning speeds and exposure times can be set.

8. Easy to operate, all parameters can be adjusted as needed on the touch screen.

Model	SCUV- LED Scan LED EXPOSURE MACHINE
Plate size(MAX)	760*640	1220*920	1520*1060	2030*1060	2030*1320	2540*1320
Power supply	4.5kw	5kw	7kw	7kw	8.5kw	8.5kw
Voltage	220V 1 phase 50-60HZ		380V 1 phase 50-60HZ
Dimensions (LxWxH)	150012001000	196014801000	226016201000	277018801000	277018801000	328018801000
Weight, equipment	350kg	400kg	450kg	500kg	550kg	600kg
